RF Modulator AV To RF Converter M61A AV TO RF CH3/CH4 Channels Video Input Adapter For VHF Demodulator Converter

Specifications: Model: M61A Standard: NTSC Material: ABS Frequency : CH3=61.25 / CH4=67.25 Output Impedance: 75 OHm Output Level: 80±5dBμV Sound System: M=4.5 Video Input Impedance: 75 Ohms/1k Ohms (Switch able) Audio Input Impedance: 13±3k Ohms TV to Insertion Loss 50-860: -6±2dB A/V Connector: RCA female RF Input: F female RF Output: F female Power Consumption: USB 5V DC Operating Temperature: 0℃ ~ +40℃ Item Size: 62 * 63 * 25mm / 2.44 * 2.48 * 0.98in Item Weight: 52g / 1.83oz Package Weight: 107g / 3.77oz Package Size: 13 * 10 * 3cm / 5.12 * 3.94 * 1.18in Package List: 1 * RF Modulator 1 * USB Cable 1 * User Manual (English) The RF modulator is fit for your own local CATV system. The VHF demodulator converter has personalised design, exquisite workmanship, making you fondle admiringly. The RF modulator is made of high quality plastic material, sturdy, High quality and long service life. Professional manufacturing, stable characteristics and high reliability.
