C & A Scientific Premiere MS-01L Compound Pakistan

The C & A Scientific Premiere MS-01L Basic Monocular Compound Microscope has a 10x eyepiece with pointer, a forward-facing nosepiece with three DIN achromatic objectives that are parcentered and parfocal, LED illumination, nested coarse and fine focus, disc diaphragm, and a plain stage with stage clips. Achromatic objectives provide color correction of magnified images. A forward-facing nosepiece eases changing objectives. The 40xR objective is retractable and spring-loaded to prevent damage to the slide or objective when focusing. A basic compound microscope is used in classroom, home school, and hobbyist settings for inspection and dissection of specimens when two-dimensional images are desired. The microscope has lower (diascopic) Brightfield illumination that transmits light up through the specimen for enhanced visibility of translucent and transparent objects. Coaxial coarse and fine focus knobs are nested to speed focusing for left-and right-handed viewers. Microscope Head and Optics SpecificationsHeadMonocularMagnification range40x-400xHead inclination45 degreesEyepiece10x with pointerNosepieceForward-facingObjectives, DIN achromatic, parcentered, parfocal4x, 10x, 40xR (retractable)Microscope Illumination and Stage SpecificationsFocus typeCoaxial nested coarse and fineLight sourceLEDDiaphragmDiscIllumination typeBrightfieldStage typePlain with stage clipsStage dimensions4.31 x 4.38 inches (W x D)Power110V or rechargeable batteryW is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back. Microscopes are instruments used to enhance the resolution of an object or image. Types include compound, stereo, or digital. Stereo microscopes show object depth in a three-dimensional image. Microscopes can have monocular (one), binocular (two), or trinocular (three) eyepieces, with varying magnification abilities. Magnification ability refers to the size of an image. Resolution, also known as resolvant power, refers to the clarity of the image. The interaction between field of view (FOV), numerical aperture (NA), and working distance (WD) determines resolution. Microscopes can control magnification through a fixed focus, or through a range of adjustments. They can also utilize LED, fluorescent, and mirror light sources to help control viewing capabilities. Microscopes are widely used in education, lab research, biology, metallurgy, engineering, chemistry, manufacturing, and in the medical, forensic science, and veterinary industries. 4x DIN achromatic, parfocal, parcentered objective 40xR DIN achromatic, parfocal, parcentered objective Compound microscope provides high magnification for biological use and educational applications Monocular viewing head with 10x eyepiece with pointer, fixed 45-degree vertical inclination to reduce eye and neck strain, and 360-degree rotation capability to provide a more comprehensive view and enable sharing Brightfield, LED illumination and six-hole disc diaphragm for clear examination and light control 45° Inclined monocular head, rotatable 360° 10X WF Eyepieces & 4x, 10x & 40x DIN Objectives 40X to 400X magnification Coaxial coarse & fine focusing20W Tunsten lamp
